Hi everyone.
I created a digital camera with STM32 Discovery board.
I'd introduce it in this video
This is the camera I created
This is the front side, and a camera module is mounted here
On the back side, you can see 3.2 inch display
and buttons and dial for control are on the right side
On the side, there is a USB connecter. so you can supply power from USB charger like this.
Finally, SD card slot is here
So let's turn on the power
Connecting USB cable here,
You can see liveview image
I'm shaking my hand,,,
Responsivity is pretty nice, and FPS is OK
Now, let's take some pictures
I need some objects...
One is colorful so that I can check the color later
and the other one
So, I'm taking a photo of the left object first
You can see color is shown appropreately.
By pushing the button on the top right, you can take a photo.
I'm taking the other one
Due to narrow FOV, it looks like this...
anyway, I got two photos now
then, by pushing the bottom right button, it enters playback mode
and you can see the picture I took
By rotating the dial, the next content is displayed
I move to recording mode again.
As for this dial,
Usual cameras on the market, this kind of dial is used to change camera settings
such as ISO and shutter speed
but the camera module I used
it doesn't have iris, so f number is fixed
as for gain(ISO) and shutter speed
This camera module takes care of AGC and AE control
So, I don't need to control these stuffs.
and there is nothing to do with this dial
So, in this project, I assigned JPEG encode quality setting to this dial
When I rotate this dial, a blue bar appears
When it goes to left, JPEG quality is low
Then, I'm taking a picture with this setting
then, set the JPEG encode quality as high
take another one
let's see the differences
move to playback mode
This is the photo I took with low quality
This is very noisy and you can see even macro block
This is the photo with High quality
You can use this dial like this
Finally, I'd like to introduce is
you can take movie as well
There is a dial in the middle, and you can actually push this
by pushing this button
you can start movie record
during recording, fps becomes slow
due to heavy load
FPS is around 5fps
anyway, recording movie now...
it's enough
by pushing this button again
movie record is finished
move to playback mode by pushing mode button
skip the previous contents
yes
this is a movie I recorded now
During movie play, you can pause it by pushing middle button
By pushing it again, you can restart movie play
pause
play
pause
play
When it reaches the end, movie play stops
As you saw
you can capture still photo and record movie
and play them
These contents is recorded
as JPEG and Motion JPEG
Since they are common formats
the contents saved in the SD card must be played in PC
So, let's check it next
In my desktop PC,
I inserted the SD card
In the SD card
you can find four JPEG files and one movie file
I open one of them
This is the first photo
This is the second one
The third one
with low JPEG quality
therefore the size is very small
Image is very noisy, though
This is the fourth image with high quality
so the file size is a little big
and the last content is
the movie file of motion JPEG
I can play it in movie player
but, this motion JPEG format
doesn't contain FPS information
so, play speed depends on player software
so, it looks like fast-forward play
anyway, like this
because the contents created in camera is normal format, you can play them in PC
Then, I'd like to play the contents created in PC
I don't need them anymore
I create some jpeg files
The first image size is 320x240
save it to the SD card
as JPEG file
This is the jpeg file I created now
For playback mode
The camera can play a variety of size
So I create a big landscape image
and save it as test2.jpg
then I will create portrait image
Now I have three contents in total
Next, I'm making movie file
I got a free contents from the internet
easy to check color
The camera is not as powerful as to decode mp4 file
So, I'll convert mp4 into motion JPEG
I need some command works for this
First, I need to populate jpeg files from the mp4 frame by frame
To do this, I use ffmpeg
I create the folder to contain it, first
run ffmpeg
this is the filename
the camera can play movie up to 10 fps
so I set fps as 10fps
The camera can decode big image, but
it takes time to resize
so I make the size small now
use the same size as display, I mean 320x240
Now I got bunch of JPEG files
Motion JPEG is a file combining these JPEG files
So I use command again
copy in binary mode
copy all the jpeg files in temp folder to one avi file
done
I don't need them
Now, let's play these contents in the camera
this is the sd card containing the contents
tuen the power on
move to play back mode
This is the first created JPEGfile
The second one
When I open big image
it is automatically adjusted to display size (320x240
regardless of aspect
This is the movie file
The motion JPEG movie file is played well
At the end, I'd like to summarize the spec of the camera
Still photo capture is available
JPEG format is supported and the size is 320x240
Movie record is available
as motion JPEG format
The maximum fps is 5fps
In playback mode,
you can play JPEG file
In addition to the contents captured in the camera itself
You can play JPEG file created in another device such as PC
The maximum size is 2560 x 1920
I didn't show it now, but
you can play RGB555 format file
, which is a similar format as bitmap
as for movie, fps is around 10fps in playback mode
These contents can be stored in SD card with FAT32 format
You can find source code in my GitHub
You can find software and hardware design document as well
Please check it if you are interested
Thank you for watching!!!
