Yes friends hello.
Today in GSM Communication
Samsung Galaxy Note 8
we will do the screen change.
Yes, as you can see, the screen is broken.
Let's show it like this.
The screen is broken. He had a heart attack.
The screen is completely broken from the inside.
Samsung Galaxy Note 8 screen replacement
we will try to show you how.
fıyttt
Yeah, we're pulling your pencil.
keychain
We're removing the sim card slot.
Samsung Galaxy Note 8 screen replacement
friends who are starting to dismantle the back cover.
First we heat the back cover.
For easy removal of the cover.
The only thing you should be aware of
not to heat the camera towards the glass.
Edges.
Yes after warming up on the edge
technician is opening with a comb.
Friends here is what you need to watch out for
back cover
Finger reader is holding the key flexi.
Be very careful there. Otherwise
flexe damage. You pull off.
Flex is attached to the cover and motherboard.
Let's show it like this. The part where Flex is.
There. You see, flexi. Be very careful here
Do not pull the cover up.
After you remove the socket, as you can see.
Fingerprint flexi button.
Finger reader.
thunderstorm
We're opening the screws.
Back cover screw sizes
They are all the same friends.
Yeah. Number of back cover screws
16 pieces.
We've removed 16 screws
Let's make sure friends.
Yeah. Currently the back cover
What we call NFC, what we call wireless charger
dismantling the part.
NFC: The track that allows the phone to receive wireless charging.
Let's show it like this. NFC (Near Field Comminucation)
Wireless charging part. As you see.
Friends. When you repair a device.
The first thing you need to do is disconnect the current from the device.
So remove the battery socket
disconnect the current from the device.
Otherwise, a very serious short circuit
why could it be.
Firstly, we remove the battery socket.
After that, we're going to start other operations.
Here's the piece
ringer, as well as a network antenna.
fence
Pencil socket and
removing the touch screen sockets.
Sensor socket. This is the last time
This is the sensor socket. When we search
screen
These are also front camera sockets.
This is the socket we disconnected
on / off socket. On-off button socket friends
There's a black screw holding the motherboard.
Do not mix with this. Instead of
if we install these other white screws
Goes up to the screen and repeat the screen
you break. As you can see, their size is different.
The screw is the black screw that holds the motherboard.
These are
Headphone socket and charging socket
microphone location
are the screws that hold it.
A total of 4 white 1 black
we have screwed the small screw.
External headphone socket
we remove the socket called the external headphone socket.
Friends. This video is for information purposes only.
It is for our technicians who follow us.
Non-experts, watching our video
we do not recommend repair or screen exchange
We're taking out the motherboard right now. Friends on a device
most
the main board.
The motherboard is the device itself. Therefore,
Remove the motherboard with great precision, big
pay attention to replace with precision.
We are removing the mains cables.
Yeah, that piece. As you see.
Charging socket, microphone
At the same time, it is the part that holds the mains cables
al.
As you can see on the motherboard
There are cameras. (rear cameras)
The motherboard is the device itself friends.
All other parts are available. But the motherboard
the device itself. For him
Let's be very careful when removing the motherboard.
Vibration motor, which allows the device to vibrate
We're removing the piece.
We're removing the sensor part. Same time
The light sensor is also there. Burning message
light ledi is here.
It is also a sensor.
When we get the phone to our ear
blackout
During the call.
Friends. This is the liquid we poured
It is a volatile substance. For easy removal of the battery.
No damage to the battery.
Have peace of mind about it. You can use it.
We're removing the battery right now.
As you see. Battery without any damage
precision output.
Yes it is
Our screen. Our broken screen.
All other parts
we'll put them all on the new screen.
Now let's see the parts we've dismantled.
Motherboard.
You ask.
Vibration motor.
Camera.
External headphone socket.
Front camera.
Charge socket, microphone.
It is also the part where the network antennas are located.
Battery.
Ringtone. We also call the network antenna.
What we call NFC and wireless charger.
Bluetooth, wireless.
Pen.
Sim card slot.
As you see. The phone is all these pieces.
And there's a back cover.
All of these parts we removed from the device
We'il put it on our new screen.
These parts are the device itself as you see it.
We're gonna put all this on the new zero screen.
As I said, the most important part of the device is the motherboard.
The remaining parts are included.
But the motherboard is the device itself.
As you can see the zero screen.
Samsung Galaxy Note 8
black screen.
With the sequence of parts we have
New zero screen will put friends.
As I said, when we attach the parts to the new screen
We need to be most careful
screw
You ask. As you can see, we're wearing the sensor.
We're wearing the vibration motor right now.
The piece that vibrates the device.
We're plugging the motherboard into the socket with the charging socket
Charging socket and microphone.
We're installing the network antennas.
Cables.
We're putting the motherboard on the new screen right now.
Yeah
After making sure the motherboard is seated
to other parts.
External headphone socket
We are installing the display and touch sockets.
Display and touch sockets.
Also pencil socket.
Also the sensor socket.
Power key socket.
We're wearing front cameras.
The motherboard screw is black.
There is one screw that holds the motherboard screw.
For this screw
we need to replace it. As you see Siya.
We removed the other 4 screws from the charging socket part.
We're putting them in place.
As we said, first
Which device to do the repair which
First we cut the current from the device.
So let's remove the battery socket.
After I repair the device. This screen changes
or any repairs happen. Last
We're wearing the battery. First from device
cutting current, giving the latest current.
What we call a ringer, and what we call a network antenna
we're wearing the piece.
NFC, what we call ENEFSİ
we're wearing the piece.
Wireless charging wifi bluetooth
function
When we put the last cover on
our remaining screw set is 16
after making sure that the screws are
replace
These are all the same size.
As we say friends this is our video
to inform our technicians who are our subscribers and of course for our valuable viewers
First time Samsung Galaxy Note screen exchange
We will make our technician our friends
for inexperience
This video was taken. Please contact
people watching our video
Screen Replacement, Samsung Galaxy Note 8 Screen Replacement
do not recommend. Let's warn about it.
Doing so may cause serious damage to the device.
Note 8 screen change only for the first time
We will make our technician see our friends
According to him, novelties for informative purposes.
After attaching all screws
Insert the finger reader socket
Inserting the finger reader socket
seated on the cover.
We're wearing the pen.
We're wearing the sim card slot.
We'll test the screen right now.
Come on, Bismillahirrahmanirrahim (in the name of Allah, the Most Gracious)
We're going to test the screen we're wearing now.
As you can see, Samsung Galaxy
Note 8 display change
Successfully realized. For watching
thank you.
Let's put his old screen next to him.
Broken screen. Samsung Galaxy
Note 8 display change
successfully accomplished. Thanks for watching.
